Home » Products » Compression springs » d-275 Url teilen URL was copied to clipboard, successfully ! Overview The Item has been added to your shopping cart. Compression spring D-275 Spring steel Ø 2.5 x 20 x 54 mm Scaled prices - Compression spring D-275 Quantity Single price [EUR] 1 5.0100 EUR 2 3.5300 EUR 3 3.3700 EUR 7 2.1400 EUR 17 1.0400 EUR 37 0.6600 EUR 75 0.5000 EUR 125 0.4132 EUR 175 0.3696 EUR 250 0.3256 EUR 350 0.2842 EUR 450 0.2464 EUR Compression spring Buy Product image Compression spring D-275 Quantity:Quantity: Add to shopping cart Technical Data - Compression spring D-275 Formula symbols Value Unit Description Material EN 10270-1 - Type of material Spring ends Closed and ground - Spring ends F1 N prestressed spring force L1 mm Prestressed spring length s1 mm Prestressed spring deflection F2 N Loaded spring force L2 mm Loaded spring length s2 mm Loaded spring deflection d 2.5 mm Wire diameter Di mm Inner coil diameter D 20 mm Mean coil diameter De 22.5 mm Outer coil diameter Dd 16.8 mm maximum diameter of mandrel Dh 23.3 mm minimum diameter of bush L0 54 mm unstressed spring length Lk mm buckling length Fn 292.131 N maximum force in static use Ln 21.7 mm Minimum length in static use sn 32.3 mm Maximum spring deflection in static use Fndyn 245.101 N maximum force in dynamic use Lndyn 26.9 mm Minimum length in dynamic use shdyn 9.97 mm Maximum stroke in dynamic use S 9.364 mm pitch of spring n 5.5 pc. number of active coils nt pc. total number of coils R 9.044 N/mm Spring rate Weight 18.2849 g weight of one spring Fntol 14.98 N (+/-) tolerance of maximum force in static use Fndtol 14.8 N (+/-) tolerance of maximum dynamic force Detol 0.35 mm (+/-) tolerances of outer coil diameter L0tol 1.17 mm (+/-) tolerance of unstressed spring length Price group G - price group F1tol N (+/-) tolerance of prestressed spring force F2tol N (+/-) tolerance of loaded spring force Technical drawing Compression spring Datasheet Compression spring D-275 Spring steel Ø 2.5 x 20 x 54 mm Datasheet download pdf file Metal spring characteristic Compression spring D-275 Spring steel Ø 2.5 x 20 x 54 mm Metal spring characteristic download pdf file CAD data Compression spring D-275 Spring steel Ø 2.5 x 20 x 54 mm CAD models download: step, stl, iges ... force-path-calculation Compression spring D-275 Spring steel Ø 2.5 x 20 x 54 mm force-path-calculation Compression spring D-275 Inquiry formular Compression spring D-275 Spring steel Ø 2.5 x 20 x 54 mm Inquiry formular Compression spring D-275 Similar compression springs to Compression spring D-275 Spring steel Ø 2.5 x 20 x 54 mm Below you will find similar Compression Springs that differ from the current spring in terms of material, dimensions and spring force. The spring highlighted in green is the most similar. A similar Compression Spring made from a different material The Compression Spring shown below has the same dimensions but is made of a different material. Please check the spring forces. article number Material d (mm) De (mm) L0 (mm) Fn (N) Ln (mm) sn (mm) n (pc.) R (N/mm) Similarity in %: Overall | Geometrie | Load | Stiffness D-275 EN 10270-1 2.5 22.5 54 292.131 21.7 32.3 5.5 9.044 100.0 | 100.0 | 100.0 | 100.0 VD-275 1.4310 2.5 22.5 54 252.891 21.45 32.56 5.5 7.768 92.9 | 100.0 | 92.9 | 85.9 Number of similar metal springs: 2 Similar Compression Springs with varying levels of spring force To compare forces, enter the length of the loaded spring [L2] or the loaded spring deflection [s2] and click [Update]. Dimensions are subject to a tolerance of up to +/- 30 %. L2 (mm) Loaded spring length s2 (mm) Loaded spring deflection Priority De (mm) Outer coil diameter L0 (mm) unstressed spring length R (N/mm) Spring rate article number De (mm) L0 (mm) R (N/mm) Material Fn (N) Ln (mm) sn (mm) Similarity in %Overall | Geometrie | Load | Stiffness D-206A 24 60.9 0.969 EN 10270-1 49.204 10.11 50.79 43.5 | 79.5 | 40.2 | 10.7 D-206D-14 20.4 58 1.037 EN 10270-1 46.269 13.4 44.6 45.2 | 79.9 | 44.1 | 11.5 D-207JR 22 50.7 1.088 EN 10270-1 39.526 14.39 36.31 49.1 | 83.9 | 51.2 | 12.0 D-207J-71 20 55 1.481 EN 10270-1 60.78 13.96 41.04 49.5 | 82.4 | 49.8 | 16.4 D-208 21.6 48 2.384 EN 10270-1 83.218 13.1 34.9 56.6 | 83.0 | 60.5 | 26.4 D-247D-06 20 50 2.541 EN 10270-1 48.599 30.87 19.13 51.1 | 87.2 | 37.9 | 28.1 D-232L-01 20 56 2.729 EN 10270-1 102.987 18.26 37.74 58.8 | 85.8 | 60.4 | 30.2 D-239A-14 23.5 58 2.982 EN 10270-1 119.251 18.01 39.99 61.1 | 89.6 | 60.8 | 33.0 D-232L 20 51.5 3.225 EN 10270-1 114.475 16.01 35.49 62.1 | 85.4 | 65.1 | 35.7 D-240A 22 55.4 3.705 EN 10270-1 139.476 17.75 37.65 66.5 | 91.8 | 66.8 | 41.0 D-241 22 62 3.705 EN 10270-1 156.147 19.85 42.15 64.8 | 88.3 | 65.0 | 41.0 D-263K 24 59.1 4.188 EN 10270-1 165.885 19.49 39.61 68.8 | 91.0 | 69.2 | 46.3 D-275A 22.5 60 5.852 EN 10270-1 173.137 30.42 29.59 78.9 | 96.7 | 75.4 | 64.7 D-273A-04 24 52 7.28 EN 10270-1 220.957 21.65 30.35 87.3 | 96.7 | 84.8 | 80.5 D-275 22.5 54 9.044 EN 10270-1 292.131 21.7 32.3 100.0 | 100.0 | 100.0 | 100.0 D-305A 23.2 61 15.709 EN 10270-1 362.67 37.91 23.09 73.8 | 87.9 | 76.0 | 57.6 D-288Z-52 21 60.5 16.646 EN 10270-1 417.371 35.43 25.07 72.3 | 88.6 | 73.8 | 54.3 D-308A-01 22 56 21.435 EN 10270-1 470.668 34.04 21.96 66.0 | 90.8 | 65.0 | 42.2 D-305 23.2 49.5 24.278 EN 10270-1 551.326 26.79 22.71 62.6 | 88.9 | 61.6 | 37.3 D-288X-06 19.4 51 24.677 EN 10270-1 542.897 29 22 62.2 | 89.0 | 61.0 | 36.7 D-313L-02 25 57 24.942 EN 10270-1 517.412 36.26 20.74 60.4 | 84.7 | 60.3 | 36.3 D-310A 19.2 54 27.453 EN 10270-1 357.433 40.98 13.02 60.6 | 87.8 | 61.0 | 32.9 D-313N-10 22.5 60 33.793 EN 10270-1 742.903 38.02 21.98 55.6 | 86.5 | 53.7 | 26.8 D-313A-06 19.5 51 35.521 EN 10270-1 511.708 36.59 14.41 54.0 | 85.6 | 50.9 | 25.5 D-336 24 49 59.273 EN 10270-1 946.882 33.03 15.98 45.9 | 82.3 | 40.2 | 15.3 D-339A-01 21.5 50 74.865 EN 10270-1 947.308 37.35 12.65 43.5 | 83.5 | 35.0 | 12.1 D-339T-10 22 50 141.723 EN 10270-1 1729.023 37.8 12.2 38.6 | 82.0 | 27.3 | 6.4 D-339T 22 44.9 141.723 EN 10270-1 1149.877 36.79 8.11 36.8 | 78.8 | 25.3 | 6.4 Number of similar metal springs: 27 Customs tariff number: 73202081; Compression spring D-275 Country of origin: DE, German; Compression spring D-275 Product image - Compression springs D-275 QR-Code: Compression spring D-275
