Home » Products » Extension Springs » z-130k-02x Url teilen URL was copied to clipboard, successfully ! Overview The Item has been added to your shopping cart. Extension Spring Z-130K-02X Spring steel Ø 1.8 x 20 x 170 mm / 270° Scaled prices - Extension Spring Z-130K-02X Quantity Single price [EUR] 1 7.1700 EUR 2 4.5200 EUR 3 3.5600 EUR 7 3.0400 EUR 17 1.6000 EUR 37 1.2900 EUR 75 1.1600 EUR 125 1.0882 EUR 175 1.0680 EUR 250 1.0487 EUR 350 1.0339 EUR 450 0.9731 EUR Extension Spring Buy Product image Extension Spring Z-130K-02X Quantity:Quantity: Add to shopping cart Technical Data - Extension Spring Z-130K-02X Formula symbols Value Unit Description Material EN 10270-1 - type of material Eylet shape 1/1 deutsche - Eylet shape F1 N prestressed spring force L1 mm Prestressed spring length s1 mm prestressed spring deflection F2 N loaded spring force L2 mm loaded spring length s2 mm loaded spring deflection Eyelet position 270 ° Eyelet position d 1.8 mm Wire diameter D mm mean coil diameter De 20 mm outer coil diameter Dh 23.2 mm minimum bush diameter L0 170 mm length of unstressed spring, measured from inner edge of loop to inner edge of loop Lk 143.55 mm length of unstressed spring body Ln 587.57 mm maximum spring length, inner loop to inner loop sn 417.57 mm Maximum spring deflection Fn 100.9 N Maximum spring force n pc. Number of aktive coils nt pc. total number of coils Lh 13.22 mm distance of inner edge of loop from the spring body R 0.225 N/mm Spring rate F0 6.881 N initial tension Fntol 4.85 N (+/-) tolerance of maximum spring force L0tol 3 mm (+/-) tolerance of unstressed length Detol 0.45 mm (+/-) tolerance of outer coil diameter Oesttol 58 degree (+/-) tolerance of loop position Weight 92.612 g weight of one spring Price group ZO - price group Technical drawing Extension Spring Datasheet Extension Spring Z-130K-02X Spring steel Ø 1.8 x 20 x 170 mm / 270° Datasheet download pdf file Metal spring characteristic Extension Spring Z-130K-02X Spring steel Ø 1.8 x 20 x 170 mm / 270° Metal spring characteristic download pdf file CAD data Extension Spring Z-130K-02X Spring steel Ø 1.8 x 20 x 170 mm / 270° CAD models download: step, stl, iges ... force-path-calculation Extension Spring Z-130K-02X Spring steel Ø 1.8 x 20 x 170 mm / 270° force-path-calculation Extension Spring Z-130K-02X Inquiry formular Extension Spring Z-130K-02X Spring steel Ø 1.8 x 20 x 170 mm / 270° Inquiry formular Extension Spring Z-130K-02X Similar extension springs to Extension Spring Z-130K-02X Spring steel Ø 1.8 x 20 x 170 mm / 270° Below you will find similar Extension Springs that differ from the current spring in terms of material, dimensions and spring force. The spring highlighted in green is the most similar. A similar Extension Spring made from a different material The Extension Spring shown below has the same dimensions but is made of a different material. Please check the spring forces. article number Material d (mm) De (mm) L0 (mm) Fn (N) Ln (mm) sn (mm) R (N/mm) Similarity in %: Overall | Geometrie | Load | Stiffness Z-130K-02X EN 10270-1 1.8 20 170 100.9 587.57 417.57 0.225 100.0 | 100.0 | 100.0 | 100.0 RZ-130K-02X 1.4310 1.8 20 170 84.95 580.6 410.6 0.193 92.3 | 100.0 | 91.3 | 85.6 Number of similar metal springs: 2 Similar Extension Springs with varying levels of spring force To compare forces, enter the length of the loaded spring [L2] or the loaded spring deflection [s2] and click [Update]. Dimensions are subject to a tolerance of up to +/- 30 %. L2 (mm) loaded spring length s2 (mm) loaded spring deflection Priority De (mm) outer coil diameter L0 (mm) length of unstressed spring, measured from inner edge of loop to inner edge of loop R (N/mm) Spring rate article number De (mm) L0 (mm) R (N/mm) Material Fn (N) Ln (mm) sn (mm) Similarity in %Overall | Geometrie | Load | Stiffness Z-118DX 21.6 172 0.095 EN 10270-1 67.4 838.73 666.73 66.7 | 93.4 | 64.7 | 41.8 Z-130K-02X 20 170 0.225 EN 10270-1 100.9 587.57 417.57 100.0 | 100.0 | 100.0 | 100.0 Z-136EX 22 186 0.262 EN 10270-1 123.3 622.72 436.72 88.4 | 90.8 | 88.7 | 85.6 Z-130K-01X 20 145 0.274 EN 10270-1 100.9 488.33 343.33 89.5 | 95.1 | 91.1 | 82.2 Z-136DX 22 170 0.292 EN 10270-1 123.3 561.82 391.82 86.1 | 93.6 | 87.8 | 76.8 Z-130KX 20 136 0.297 EN 10270-1 100.9 452.82 316.82 85.7 | 93.3 | 87.9 | 75.9 Z-136CX 22 154 0.33 EN 10270-1 123.3 500.88 346.88 80.3 | 90.5 | 82.5 | 68.0 Z-141EX 18 180 0.512 EN 10270-1 149.2 448.6 268.6 67.0 | 91.5 | 66.0 | 43.5 Z-138AX 18.6 160 0.534 EN 10270-1 144.7 410.87 250.87 66.4 | 92.4 | 64.9 | 41.9 Z-141DX 18 164 0.571 EN 10270-1 149.2 404.96 240.96 64.6 | 92.2 | 62.7 | 39.0 Z-138X 18.6 147 0.587 EN 10270-1 144.7 375.32 228.32 63.4 | 89.8 | 62.2 | 38.1 Z-147K-04X 20 156 0.72 EN 10270-1 176.1 380.1 224.1 59.1 | 91.2 | 55.5 | 30.7 Z-147K-03X 20 134 0.868 EN 10270-1 176.1 319.96 185.96 54.4 | 86.9 | 50.9 | 25.5 Z-156BX 22.5 165 0.925 EN 10270-1 223.8 387.73 222.73 53.1 | 86.0 | 49.2 | 24.0 Z-156MX 20 203.5 1.05 EN 10270-1 249.9 422.42 218.92 50.9 | 85.2 | 46.4 | 21.2 Z-156LX 20 191 1.129 EN 10270-1 249.9 394.45 203.45 50.4 | 87.0 | 44.5 | 19.7 Z-156KX 20 163.5 1.356 EN 10270-1 249.9 332.91 169.41 48.7 | 89.4 | 40.5 | 16.4 Number of similar metal springs: 16 Customs tariff number: 73202085; Extension Spring Z-130K-02X Country of origin: DE, German; Extension Spring Z-130K-02X Product image - Extension Springs Z-130K-02X QR-Code: Extension Spring Z-130K-02X
