Home » Products » Torsion springs » t-19202r Url teilen URL was copied to clipboard, successfully ! Overview The Item has been added to your shopping cart. Torsion spring T-19202R: Stainless steel Ø 2.5 x 10 x 75 mm / 180° Scaled prices - Torsion spring T-19202R Quantity Single price [EUR] 1 5.4200 EUR 2 3.8200 EUR 3 3.6400 EUR 7 2.6600 EUR 17 1.3800 EUR 37 1.0200 EUR 75 0.8900 EUR 125 0.5823 EUR 175 0.5445 EUR 250 0.4945 EUR 350 0.4610 EUR 450 0.4169 EUR Torsion spring Buy Product image Torsion spring T-19202R Quantity:Quantity: Add to shopping cart Technical Data - Torsion spring T-19202R Formula symbols Value Unit Description Material 1.4310 - Type of material Coiling direction Right - Coiling direction Leg position 180 degree Leg position when relaxed alpha1 degree prestressed rotational angle F1 N prestressed spring force M1 Nmm torque by angle alpha1 alpha2 degree loaded rotational angle F2 N loaded spring force M2 Nmm torque by angle alpha2 alphah degree working rotational angle d 2.5 mm Wire diameter Di 10 mm inner coil diameter Dd mm diameter of mandrel LsH mm leg length of the lever leg LsR mm leg length of the recumbent leg Lk0 13.75 mm length of spring body Ls 75 mm leg length RH mm leverage Mntol 569.84 Nmm (+/-) Tolerance maximum torque Mn 1422.19 Nmm maximum torque alphan 40.66 degree maximum rotational angle nt 4.5 pc. total number of coils Ddmax 9 mm maximum possible mandrel diameter Ddmin 8 mm Min. possible mandrel diameter Ditol 0.27 mm (+/-) tolerance of inner coil diameter Weight 12.6438 g weight of one spring Price group L - price group Technical drawing Torsion spring Datasheet Torsion spring T-19202R: Stainless steel Ø 2.5 x 10 x 75 mm / 180° Datasheet download pdf file Metal spring characteristic Torsion spring T-19202R: Stainless steel Ø 2.5 x 10 x 75 mm / 180° Metal spring characteristic download pdf file CAD data Torsion spring T-19202R: Stainless steel Ø 2.5 x 10 x 75 mm / 180° CAD models download: step, stl, iges ... force-path-calculation Torsion spring T-19202R: Stainless steel Ø 2.5 x 10 x 75 mm / 180° force-path-calculation Torsion spring T-19202R Inquiry formular Torsion spring T-19202R: Stainless steel Ø 2.5 x 10 x 75 mm / 180° Inquiry formular Torsion spring T-19202R Similar torsion springs to Torsion spring T-19202R: Stainless steel Ø 2.5 x 10 x 75 mm / 180° Below you will find similar Torsion Springs that differ from the current spring in terms of dimensions and spring force. The spring highlighted in green is the most similar. Similar Torsion Springs with varying levels of spring force To compare forces, enter the applied angle of rotation [alpha2] and click [Update]. Dimensions are subject to a tolerance of up to +/- 30 %. alpha2 (degree) loaded rotational angle Priority Di (mm) inner coil diameter Lk0 (mm) length of spring body Mn (Nmm) maximum torque article number Di (mm) Lk0 (mm) Mn (Nmm) alphan (degree) Material Similarity in %Overall | Geometrie | Load | Stiffness T-18810R 8.9 12 429.24 88.69 1.4310 44.0 | 80.1 | 38.0 | 13.8 T-18835R 11.9 12 441.52 117.28 1.4310 40.7 | 78.4 | 32.9 | 10.8 T-18860R 14.4 12 449.91 141.55 1.4310 37.6 | 73.6 | 30.2 | 9.1 T-18910R 10 13.5 554.97 80.37 1.4310 51.5 | 90.1 | 44.8 | 19.7 T-18906R 10 8.1 554.97 43.28 1.4310 60.0 | 77.0 | 66.5 | 36.7 T-18902R 10 6.3 554.97 30.91 1.4310 60.5 | 72.6 | 57.5 | 51.3 T-18922R 13.5 13.5 572.76 107.55 1.4310 45.2 | 81.4 | 39.0 | 15.2 T-18934R 16 13.5 581.21 126.97 1.4310 42.4 | 77.6 | 36.4 | 13.1 T-19110R 11 15 798.72 83.67 1.4310 55.7 | 87.5 | 52.4 | 27.3 T-19106R 11 9 798.72 45.07 1.4310 67.5 | 78.8 | 73.2 | 50.7 T-19102R 11 7 798.72 32.21 1.4310 70.8 | 73.9 | 67.7 | 70.9 T-19135R 15 15 825.31 113.04 1.4310 49.1 | 79.4 | 47.0 | 20.9 T-16806R 11.5 12.38 1041.37 49.83 1.4310 75.4 | 89.0 | 77.4 | 59.7 T-16802R 11.5 7.88 1041.37 27.69 1.4310 80.6 | 78.1 | 70.7 | 93.0 T-19202R 10 13.75 1422.19 40.66 1.4310 100.0 | 100.0 | 100.0 | 100.0 T-19222R 13.5 13.75 1481.57 54.23 1.4310 85.0 | 91.4 | 85.5 | 78.1 T-16906R 11.5 15.4 1888.38 39.19 1.4310 82.3 | 88.5 | 85.8 | 72.6 T-16902R 11.5 9.8 1888.38 21.77 1.4310 62.4 | 82.5 | 64.4 | 40.3 T-19302R 12 16.5 2364.22 39.15 1.4310 73.2 | 83.3 | 78.2 | 57.9 T-17002R 12.5 11.2 2709.97 20.11 1.4310 52.3 | 79.9 | 51.0 | 26.0 T-17006R 12.5 17.6 2709.97 36.19 1.4310 65.4 | 78.8 | 70.7 | 46.7 Number of similar metal springs: 20 Customs tariff number: 73202089; Torsion spring T-19202R Country of origin: DE, German; Torsion spring T-19202R Product image - Torsion springs T-19202R QR-Code: Torsion spring T-19202R
