Home » Products » Compression springs » d-359b Url teilen URL was copied to clipboard, successfully ! Overview The Item has been added to your shopping cart. Compression spring D-359B Spring steel Ø 5 x 25 x 34 mm Scaled prices - Compression spring D-359B Quantity Single price [EUR] 1 12.4800 EUR 2 9.9500 EUR 3 5.4200 EUR 7 3.2800 EUR 17 1.8300 EUR 37 1.5400 EUR 75 1.5100 EUR 125 1.4634 EUR 175 1.4586 EUR 250 1.4345 EUR 350 1.4116 EUR Compression spring Buy Product image Compression spring D-359B Quantity:Quantity: Add to shopping cart Technical Data - Compression spring D-359B Formula symbols Value Unit Description Material EN 10270-1 - Type of material Spring ends Closed and ground - Spring ends F1 N prestressed spring force L1 mm Prestressed spring length s1 mm Prestressed spring deflection F2 N Loaded spring force L2 mm Loaded spring length s2 mm Loaded spring deflection d 5 mm Wire diameter Di mm Inner coil diameter D 25 mm Mean coil diameter De 30 mm Outer coil diameter Dd 19.1 mm maximum diameter of mandrel Dh 31 mm minimum diameter of bush L0 34 mm unstressed spring length Lk mm buckling length Fn 476.629 N maximum force in static use Ln 29.91 mm Minimum length in static use sn 4.09 mm Maximum spring deflection in static use Fndyn 335.314 N maximum force in dynamic use Lndyn 31.12 mm Minimum length in dynamic use shdyn 2.88 mm Maximum stroke in dynamic use S 8.286 mm pitch of spring n 3.5 pc. number of active coils nt pc. total number of coils R 116.429 N/mm Spring rate Weight 67.0445 g weight of one spring Fntol 101.8 N (+/-) tolerance of maximum force in static use Fndtol 99.76 N (+/-) tolerance of maximum dynamic force Detol 0.35 mm (+/-) tolerances of outer coil diameter L0tol 0.81 mm (+/-) tolerance of unstressed spring length Price group AB - price group F1tol N (+/-) tolerance of prestressed spring force F2tol N (+/-) tolerance of loaded spring force Technical drawing Compression spring Datasheet Compression spring D-359B Spring steel Ø 5 x 25 x 34 mm Datasheet download pdf file Metal spring characteristic Compression spring D-359B Spring steel Ø 5 x 25 x 34 mm Metal spring characteristic download pdf file CAD data Compression spring D-359B Spring steel Ø 5 x 25 x 34 mm CAD models download: step, stl, iges ... force-path-calculation Compression spring D-359B Spring steel Ø 5 x 25 x 34 mm force-path-calculation Compression spring D-359B Inquiry formular Compression spring D-359B Spring steel Ø 5 x 25 x 34 mm Inquiry formular Compression spring D-359B Similar compression springs to Compression spring D-359B Spring steel Ø 5 x 25 x 34 mm Below you will find similar Compression Springs that differ from the current spring in terms of material, dimensions and spring force. The spring highlighted in green is the most similar. A similar Compression Spring made from a different material The Compression Spring shown below has the same dimensions but is made of a different material. Please check the spring forces. article number Material d (mm) De (mm) L0 (mm) Fn (N) Ln (mm) sn (mm) n (pc.) R (N/mm) Similarity in %: Overall | Geometrie | Load | Stiffness D-359B EN 10270-1 5 30 34 476.629 29.91 4.09 3.5 116.429 100.0 | 100.0 | 100.0 | 100.0 VD-359B 1.4310 5 30 34 409.375 29.91 4.09 3.5 100 92.9 | 100.0 | 92.9 | 85.9 Number of similar metal springs: 2 Similar Compression Springs with varying levels of spring force To compare forces, enter the length of the loaded spring [L2] or the loaded spring deflection [s2] and click [Update]. Dimensions are subject to a tolerance of up to +/- 30 %. L2 (mm) Loaded spring length s2 (mm) Loaded spring deflection Priority De (mm) Outer coil diameter L0 (mm) unstressed spring length R (N/mm) Spring rate article number De (mm) L0 (mm) R (N/mm) Material Fn (N) Ln (mm) sn (mm) Similarity in %Overall | Geometrie | Load | Stiffness D-274 22.5 36 14.212 EN 10270-1 291.853 15.47 20.54 42.0 | 73.1 | 40.6 | 12.2 D-288Z-31 28 40 15.089 EN 10270-1 322.248 18.64 21.36 45.3 | 79.4 | 43.4 | 12.9 D-288Z-41 27 37.2 17.055 EN 10270-1 317.939 18.56 18.64 46.5 | 80.5 | 44.3 | 14.6 D-299 28.2 42.5 19.533 EN 10270-1 444.477 19.75 22.75 50.6 | 79.3 | 55.6 | 16.8 D-313J-01 31.6 33.3 22.271 EN 10270-1 247.131 22.2 11.1 50.6 | 88.3 | 44.3 | 19.1 D-303A-10 27.2 32 30.91 EN 10270-1 488.372 16.2 15.8 57.1 | 82.9 | 61.7 | 26.5 D-313J-06 28.6 38.9 31.289 EN 10270-1 529.675 21.97 16.93 56.3 | 84.9 | 57.1 | 26.8 D-304 23.2 33.5 38.151 EN 10270-1 538.84 19.38 14.12 57.1 | 80.0 | 58.7 | 32.7 D-330 29 41 47.689 EN 10270-1 800.209 24.22 16.78 56.5 | 86.5 | 42.0 | 40.9 D-313K 25 33.3 49.885 EN 10270-1 577.274 21.73 11.57 62.1 | 84.4 | 59.0 | 42.8 D-339O 32 41.7 57.392 EN 10270-1 831.766 27.21 14.49 60.2 | 88.4 | 42.8 | 49.3 D-334A-02 27 37 61.243 EN 10270-1 790.646 24.09 12.91 61.9 | 87.3 | 46.0 | 52.6 D-335 24 33.5 93.143 EN 10270-1 891.843 23.93 9.58 71.4 | 86.2 | 48.1 | 79.9 D-339R-05 27 37 104.786 EN 10270-1 1056.24 26.92 10.08 74.5 | 90.6 | 42.9 | 89.9 D-359B 30 34 116.429 EN 10270-1 476.629 29.91 4.09 100.0 | 100.0 | 100.0 | 100.0 D-339R-12 22.5 33.5 204.66 EN 10270-1 1391.685 26.7 6.8 64.0 | 87.8 | 47.2 | 56.9 D-339S 22 31.8 222.708 EN 10270-1 1139.754 26.68 5.12 66.3 | 85.6 | 60.9 | 52.3 D-364O 28 39.3 233.831 EN 10270-1 1553.052 32.66 6.64 62.1 | 90.3 | 46.1 | 49.8 Number of similar metal springs: 17 Customs tariff number: 73202081; Compression spring D-359B Country of origin: DE, German; Compression spring D-359B Product image - Compression springs D-359B QR-Code: Compression spring D-359B
