Home » Products » Compression springs » d-063q Url teilen URL was copied to clipboard, successfully ! Overview Back to overview The Item has been added to your shopping cart. Compression spring D-063Q Spring steel Ø 0.5 x 7.1 x 55 mm Scaled prices - Compression spring D-063Q Quantity Single price [EUR] 1 4.7200 EUR 2 3.3300 EUR 3 3.1700 EUR 7 1.7700 EUR 17 0.7400 EUR 37 0.4200 EUR 75 0.2000 EUR 125 0.1664 EUR 175 0.1253 EUR 250 0.1002 EUR 350 0.0758 EUR 450 0.0694 EUR Compression spring Buy Product image Compression spring D-063Q Quantity:Quantity: Add to shopping cart Technical Data - Compression spring D-063Q Formula symbols Value Unit Description Material EN 10270-1 - Type of material Spring ends Closed and ground - Spring ends F1 - N prestressed spring force L1 - mm Prestressed spring length s1 - mm Prestressed spring deflection F2 - N Loaded spring force L2 - mm Loaded spring length s2 - mm Loaded spring deflection d 0.5 mm Wire diameter Di - mm Inner coil diameter D 7.1 mm Mean coil diameter De 7.6 mm Outer coil diameter Dd 6.1 mm maximum diameter of mandrel Dh 8.4 mm minimum diameter of bush L0 55 mm unstressed spring length Lk 43.4 mm buckling length Fn 5.868 N maximum force in static use Ln 10.47 mm Minimum length in static use sn 44.53 mm Maximum spring deflection in static use Fndyn 5.689 N maximum force in dynamic use Lndyn 11.83 mm Minimum length in dynamic use shdyn 16.69 mm Maximum stroke in dynamic use S 4.037 mm pitch of spring n 13.5 pc. number of active coils nt - pc. total number of coils R 0.132 N/mm Spring rate Weight 0.5366 g weight of one spring Fntol 0.48 N (+/-) tolerance of maximum force in static use Fndtol 0.48 N (+/-) tolerance of maximum dynamic force Detol 0.35 mm (+/-) tolerances of outer coil diameter L0tol 2.98 mm (+/-) tolerance of unstressed spring length Price group B - price group F1tol - N (+/-) tolerance of prestressed spring force F2tol - N (+/-) tolerance of loaded spring force Technical drawing Compression spring Datasheet Compression spring D-063Q Spring steel Ø 0.5 x 7.1 x 55 mm Datasheet download pdf file Metal spring characteristic Compression spring D-063Q Spring steel Ø 0.5 x 7.1 x 55 mm Metal spring characteristic download pdf file CAD data Compression spring D-063Q Spring steel Ø 0.5 x 7.1 x 55 mm CAD models download: step, stl, iges ... force-path-calculation Compression spring D-063Q Spring steel Ø 0.5 x 7.1 x 55 mm force-path-calculation Compression spring D-063Q Inquiry formular Compression spring D-063Q Spring steel Ø 0.5 x 7.1 x 55 mm Inquiry formular Compression spring D-063Q Similar compression springs to Compression spring D-063Q Spring steel Ø 0.5 x 7.1 x 55 mm Below you will find similar Compression Springs that differ from the current spring in terms of material, dimensions and spring force. The spring highlighted in green is the most similar. A similar Compression Spring made from a different material The Compression Spring shown below has the same dimensions but is made of a different material. Please check the spring forces. article number Material d (mm) De (mm) L0 (mm) Fn (N) Ln (mm) sn (mm) n (pc.) R (N/mm) Similarity in %: Overall | Geometrie | Load | Stiffness D-063Q EN 10270-1 0.5 7.6 55 5.868 10.47 44.53 13.5 0.132 100.0 | 100.0 | 100.0 | 100.0 VD-063Q 1.4310 0.5 7.6 55 5.04 10.47 44.53 13.5 0.113 92.9 | 100.0 | 92.9 | 85.9 Number of similar metal springs: 2 Similar Compression Springs with varying levels of spring force To compare forces, enter the length of the loaded spring [L2] or the loaded spring deflection [s2] and click [Update]. Dimensions are subject to a tolerance of up to +/- 30 %. L2 (mm) Loaded spring length s2 (mm) Loaded spring deflection Priority De (mm) Outer coil diameter L0 (mm) unstressed spring length R (N/mm) Spring rate article number De (mm) L0 (mm) R (N/mm) Material Fn (N) Ln (mm) sn (mm) Similarity in %Overall | Geometrie | Load | Stiffness D-063L 8.5 60.5 0.131 EN 10270-1 6.866 8.05 52.45 92.7 | 93.4 | 85.2 | 99.3 D-063Q 7.6 55 0.132 EN 10270-1 5.868 10.47 44.53 100.0 | 100.0 | 100.0 | 100.0 D-068A-05 6.5 51.8 0.159 EN 10270-1 6.155 13.17 38.63 89.0 | 93.2 | 91.0 | 82.7 D-094A 8.63 55 0.169 EN 10270-1 6.455 16.9 38.1 85.1 | 89.1 | 88.2 | 77.8 D-094 8.63 55 0.251 EN 10270-1 10.826 11.83 43.17 72.4 | 89.1 | 75.6 | 52.5 D-100A 6.93 54 0.285 EN 10270-1 9.99 18.98 35.02 68.2 | 89.6 | 68.7 | 46.2 D-095E 7.9 49 0.334 EN 10270-1 12.531 11.5 37.5 64.4 | 88.2 | 65.5 | 39.4 D-100 6.93 54 0.347 EN 10270-1 13.243 15.83 38.17 64.2 | 89.6 | 65.0 | 38.0 D-115H-04 8 63 0.381 EN 10270-1 17.915 15.99 47.01 61.0 | 84.6 | 63.7 | 34.6 D-115M 7.5 56.8 0.502 EN 10270-1 21.043 14.87 41.93 58.8 | 89.0 | 61.0 | 26.3 D-115H-03 8 48 0.503 EN 10270-1 17.881 12.45 35.55 55.7 | 84.6 | 56.3 | 26.2 D-100A-03 6.4 51 0.539 EN 10270-1 20.357 13.23 37.77 55.6 | 85.4 | 56.8 | 24.4 D-132A-01 7.1 65 0.566 EN 10270-1 19.938 29.76 35.24 52.6 | 80.2 | 54.3 | 23.3 D-127E-06 8 60.8 0.604 EN 10270-1 24.85 19.68 41.12 54.1 | 82.7 | 58.0 | 21.8 D-132A 7.1 48 0.742 EN 10270-1 18.487 23.07 24.93 47.6 | 81.1 | 43.9 | 17.8 D-132 7.1 48 0.902 EN 10270-1 25.928 19.26 28.74 46.4 | 81.1 | 43.6 | 14.6 D-132E 6.4 59 0.932 EN 10270-1 31.179 25.54 33.46 47.0 | 80.0 | 47.0 | 14.1 Number of similar metal springs: 16 Customs tariff number: 73202081; Compression spring D-063Q Country of origin: DE, German; Compression spring D-063Q Product image - Compression springs D-063Q QR-Code: Compression spring D-063Q
