Home » Products » Compression springs » d-180m Url teilen URL was copied to clipboard, successfully ! Overview The Item has been added to your shopping cart. Compression spring D-180M Spring steel Ø 1.2 x 18.8 x 209 mm Scaled prices - Compression spring D-180M Quantity Single price [EUR] 1 4.9000 EUR 2 3.4600 EUR 3 3.3000 EUR 7 1.8900 EUR 17 0.9300 EUR 37 0.5700 EUR 75 0.3900 EUR 125 0.3566 EUR 175 0.3067 EUR 250 0.2817 EUR 350 0.2526 EUR 450 0.1895 EUR Compression spring Buy Product image Compression spring D-180M Quantity:Quantity: Add to shopping cart Technical Data - Compression spring D-180M Formula symbols Value Unit Description Material EN 10270-1 - Type of material Spring ends Closed and ground - Spring ends F1 N prestressed spring force L1 mm Prestressed spring length s1 mm Prestressed spring deflection F2 N Loaded spring force L2 mm Loaded spring length s2 mm Loaded spring deflection d 1.2 mm Wire diameter Di mm Inner coil diameter D 18.8 mm Mean coil diameter De 20 mm Outer coil diameter Dd 16.9 mm maximum diameter of mandrel Dh 22 mm minimum diameter of bush L0 209 mm unstressed spring length Lk 189.2 mm buckling length Fn 36.775 N maximum force in static use Ln 29.71 mm Minimum length in static use sn 179.29 mm Maximum spring deflection in static use Fndyn 35.88 N maximum force in dynamic use Lndyn 34.07 mm Minimum length in dynamic use shdyn 62.45 mm Maximum stroke in dynamic use S 13.406 mm pitch of spring n 15.5 pc. number of active coils nt pc. total number of coils R 0.205 N/mm Spring rate Weight 9.2401 g weight of one spring Fntol 2.22 N (+/-) tolerance of maximum force in static use Fndtol 2.21 N (+/-) tolerance of maximum dynamic force Detol 0.5 mm (+/-) tolerances of outer coil diameter L0tol 8.13 mm (+/-) tolerance of unstressed spring length Price group E - price group F1tol N (+/-) tolerance of prestressed spring force F2tol N (+/-) tolerance of loaded spring force Technical drawing Compression spring Datasheet Compression spring D-180M Spring steel Ø 1.2 x 18.8 x 209 mm Datasheet download pdf file Metal spring characteristic Compression spring D-180M Spring steel Ø 1.2 x 18.8 x 209 mm Metal spring characteristic download pdf file CAD data Compression spring D-180M Spring steel Ø 1.2 x 18.8 x 209 mm CAD models download: step, stl, iges ... force-path-calculation Compression spring D-180M Spring steel Ø 1.2 x 18.8 x 209 mm force-path-calculation Compression spring D-180M Inquiry formular Compression spring D-180M Spring steel Ø 1.2 x 18.8 x 209 mm Inquiry formular Compression spring D-180M Similar compression springs to Compression spring D-180M Spring steel Ø 1.2 x 18.8 x 209 mm Below you will find similar Compression Springs that differ from the current spring in terms of material, dimensions and spring force. The spring highlighted in green is the most similar. A similar Compression Spring made from a different material The Compression Spring shown below has the same dimensions but is made of a different material. Please check the spring forces. article number Material d (mm) De (mm) L0 (mm) Fn (N) Ln (mm) sn (mm) n (pc.) R (N/mm) Similarity in %: Overall | Geometrie | Load | Stiffness D-180M EN 10270-1 1.2 20 209 36.775 29.71 179.29 15.5 0.205 100.0 | 100.0 | 100.0 | 100.0 VD-180M 1.4310 1.2 20 209 31.586 29.71 179.29 15.5 0.176 92.9 | 100.0 | 92.9 | 85.9 Number of similar metal springs: 2 Similar Compression Springs with varying levels of spring force To compare forces, enter the length of the loaded spring [L2] or the loaded spring deflection [s2] and click [Update]. Dimensions are subject to a tolerance of up to +/- 30 %. L2 (mm) Loaded spring length s2 (mm) Loaded spring deflection Priority De (mm) Outer coil diameter L0 (mm) unstressed spring length R (N/mm) Spring rate article number De (mm) L0 (mm) R (N/mm) Material Fn (N) Ln (mm) sn (mm) Similarity in %Overall | Geometrie | Load | Stiffness D-145D-04 18.5 157 0.141 EN 10270-1 18.861 23.05 133.95 53.3 | 81.1 | 57.8 | 21.1 D-145H 17 186 0.16 EN 10270-1 25.834 25 161 81.3 | 85.8 | 80.0 | 78.2 D-179J 19 208 0.168 EN 10270-1 30.247 27.73 180.27 89.4 | 95.4 | 90.9 | 81.8 D-180M 20 209 0.205 EN 10270-1 36.775 29.71 179.29 100.0 | 100.0 | 100.0 | 100.0 D-185A 17.25 205 0.27 EN 10270-1 44.435 40.35 164.65 85.6 | 93.4 | 87.3 | 76.0 D-207JU 22 162 0.324 EN 10270-1 39.058 41.3 120.7 72.4 | 96.7 | 72.0 | 48.5 D-185 17.25 205 0.328 EN 10270-1 52.024 46.5 158.5 78.5 | 93.4 | 79.5 | 62.5 D-180L 20 130 0.335 EN 10270-1 37.101 19.14 110.86 76.4 | 87.4 | 80.5 | 61.3 D-212A 21.6 240 0.371 EN 10270-1 70.015 51.24 188.76 71.3 | 84.9 | 73.8 | 55.3 D-212 21.6 240 0.451 EN 10270-1 83.321 55.3 184.7 67.0 | 84.9 | 70.6 | 45.5 D-211A 21.6 165 0.451 EN 10270-1 55.172 42.7 122.3 83.3 | 100.0 | 82.3 | 67.6 D-206D-05 17.4 181 0.516 EN 10270-1 71.841 41.9 139.1 63.5 | 86.4 | 64.4 | 39.7 D-207J-80 20 152 0.603 EN 10270-1 73.674 29.9 122.1 92.2 | 92.8 | 93.4 | 90.4 D-211 21.6 165 0.668 EN 10270-1 83.122 40.5 124.5 100.0 | 100.0 | 100.0 | 100.0 D-239A-06 25 205.5 0.724 EN 10270-1 111.129 52.04 153.46 55.7 | 79.4 | 59.3 | 28.3 D-217A 17.6 165 0.724 EN 10270-1 84.615 48.2 116.8 94.0 | 93.8 | 96.0 | 92.2 D-217 17.6 165 0.881 EN 10270-1 104.056 46.9 118.1 85.7 | 93.8 | 87.4 | 75.8 D-244A 22 200 0.906 EN 10270-1 126.551 60.25 139.75 79.3 | 86.9 | 77.4 | 73.7 D-247D-09 20 200 1.035 EN 10270-1 134.611 69.96 130.04 51.7 | 85.2 | 49.9 | 19.8 Number of similar metal springs: 18 Customs tariff number: 73202081; Compression spring D-180M Country of origin: DE, German; Compression spring D-180M Product image - Compression springs D-180M QR-Code: Compression spring D-180M
