Home » Products » Compression springs » vd-264b Url teilen URL was copied to clipboard, successfully ! Overview The Item has been added to your shopping cart. Compression spring VD-264B Stainless steel Ø 2.5 x 32 x 71.5 mm Scaled prices - Compression spring VD-264B Quantity Single price [EUR] 1 5.2700 EUR 2 3.7200 EUR 3 3.5400 EUR 7 2.5100 EUR 17 1.2200 EUR 37 0.9000 EUR 75 0.7300 EUR 125 0.5070 EUR 175 0.4444 EUR 250 0.4132 EUR 350 0.3853 EUR 450 0.3536 EUR Compression spring Buy Product image Compression spring VD-264B Quantity:Quantity: Add to shopping cart Technical Data - Compression spring VD-264B Formula symbols Value Unit Description Material 1.4310 - Type of material Spring ends Closed and ground - Spring ends F1 N prestressed spring force L1 mm Prestressed spring length s1 mm Prestressed spring deflection F2 N Loaded spring force L2 mm Loaded spring length s2 mm Loaded spring deflection d 2.5 mm Wire diameter Di mm Inner coil diameter D 32 mm Mean coil diameter De 34.5 mm Outer coil diameter Dd 28.7 mm maximum diameter of mandrel Dh 35.3 mm minimum diameter of bush L0 71.5 mm unstressed spring length Lk mm buckling length Fn 91.025 N maximum force in static use Ln 23.5 mm Minimum length in static use sn 48 mm Maximum spring deflection in static use Fndyn 86.519 N maximum force in dynamic use Lndyn 25.88 mm Minimum length in dynamic use shdyn 32.44 mm Maximum stroke in dynamic use S 12.545 mm pitch of spring n 5.5 pc. number of active coils nt pc. total number of coils R 1.897 N/mm Spring rate Weight 29.2558 g weight of one spring Fntol 8.89 N (+/-) tolerance of maximum force in static use Fndtol 8.82 N (+/-) tolerance of maximum dynamic force Detol 0.6 mm (+/-) tolerances of outer coil diameter L0tol 3.31 mm (+/-) tolerance of unstressed spring length Price group K - price group F1tol N (+/-) tolerance of prestressed spring force F2tol N (+/-) tolerance of loaded spring force Technical drawing Compression spring Datasheet Compression spring VD-264B Stainless steel Ø 2.5 x 32 x 71.5 mm Datasheet download pdf file Metal spring characteristic Compression spring VD-264B Stainless steel Ø 2.5 x 32 x 71.5 mm Metal spring characteristic download pdf file CAD data Compression spring VD-264B Stainless steel Ø 2.5 x 32 x 71.5 mm CAD models download: step, stl, iges ... force-path-calculation Compression spring VD-264B Stainless steel Ø 2.5 x 32 x 71.5 mm force-path-calculation Compression spring VD-264B Inquiry formular Compression spring VD-264B Stainless steel Ø 2.5 x 32 x 71.5 mm Inquiry formular Compression spring VD-264B Similar compression springs to Compression spring VD-264B Stainless steel Ø 2.5 x 32 x 71.5 mm Below you will find similar Compression Springs that differ from the current spring in terms of material, dimensions and spring force. The spring highlighted in green is the most similar. A similar Compression Spring made from a different material The Compression Spring shown below has the same dimensions but is made of a different material. Please check the spring forces. article number Material d (mm) De (mm) L0 (mm) Fn (N) Ln (mm) sn (mm) n (pc.) R (N/mm) Similarity in %: Overall | Geometrie | Load | Stiffness VD-264B 1.4310 2.5 34.5 71.5 91.025 23.5 48 5.5 1.897 100.0 | 100.0 | 100.0 | 100.0 D-264B EN 10270-1 2.5 34.5 71.5 105.979 23.5 48 5.5 2.208 92.9 | 100.0 | 92.9 | 85.9 D-264 EN 10270-1 2.5 34.5 71.5 182.514 18.9 52.6 3.5 3.47 75.1 | 100.0 | 70.6 | 54.7 Number of similar metal springs: 3 Similar Compression Springs with varying levels of spring force To compare forces, enter the length of the loaded spring [L2] or the loaded spring deflection [s2] and click [Update]. Dimensions are subject to a tolerance of up to +/- 30 %. L2 (mm) Loaded spring length s2 (mm) Loaded spring deflection Priority De (mm) Outer coil diameter L0 (mm) unstressed spring length R (N/mm) Spring rate article number De (mm) L0 (mm) R (N/mm) Material Fn (N) Ln (mm) sn (mm) Similarity in %Overall | Geometrie | Load | Stiffness VD-207JA 35.5 74.5 0.322 1.4310 19.861 12.82 61.68 50.4 | 84.4 | 49.8 | 17.0 VD-207JF 34 69.1 0.369 1.4310 20.878 12.47 56.63 52.8 | 85.1 | 53.8 | 19.4 VD-234M 30 76 1.16 1.4310 65.707 19.33 56.67 75.5 | 87.0 | 78.4 | 61.1 VD-232F 30 69.1 1.17 1.4310 65.828 12.85 56.25 75.2 | 85.2 | 78.8 | 61.7 VD-234G 34 78.1 1.221 1.4310 77.773 14.39 63.71 78.3 | 90.0 | 80.4 | 64.4 VD-264B 34.5 71.5 1.897 1.4310 91.025 23.5 48 100.0 | 100.0 | 100.0 | 100.0 VD-268C 31 69 2.685 1.4310 124.011 22.81 46.19 83.6 | 95.5 | 84.8 | 70.6 VD-264 34.5 71.5 2.98 1.4310 159.442 18 53.5 79.0 | 100.0 | 73.4 | 63.6 VD-288Z-21 33 72.5 4.773 1.4310 218.949 26.63 45.88 67.0 | 92.5 | 68.6 | 39.7 VD-288M 30 70.7 4.859 1.4310 223.43 24.72 45.98 66.3 | 91.7 | 68.3 | 39.0 VD-298C 33 64 6.304 1.4310 226.622 28.05 35.95 58.5 | 87.8 | 57.5 | 30.1 VD-294 35.2 58.5 8 1.4310 304.8 20.4 38.1 54.8 | 86.0 | 54.6 | 23.7 VD-313J-04 31.6 72.2 8.927 1.4310 293.237 39.35 32.85 52.6 | 86.7 | 49.7 | 21.2 VD-313J-03 31.6 62.7 10.3 1.4310 284.653 35.06 27.64 48.7 | 82.9 | 44.8 | 18.4 VD-329B 35 76 10.741 1.4310 372.487 41.32 34.68 50.3 | 85.1 | 48.3 | 17.7 VD-326 36 79.5 12.429 1.4310 561.641 34.31 45.19 51.1 | 82.8 | 55.2 | 15.3 VD-325A 36 61 12.429 1.4310 331.705 34.31 26.69 46.0 | 81.2 | 41.5 | 15.3 VD-313J-08 28.6 74.6 12.541 1.4310 448.306 38.85 35.75 48.4 | 82.7 | 47.4 | 15.1 VD-329B-01 30 70 19.607 1.4310 622.571 38.25 31.75 44.2 | 82.5 | 40.4 | 9.7 VD-356 37 75 30.344 1.4310 1003.191 41.94 33.06 41.6 | 79.5 | 39.0 | 6.2 VD-355A 37 63 30.344 1.4310 639.061 41.94 21.06 37.5 | 77.1 | 29.1 | 6.2 Number of similar metal springs: 20 Customs tariff number: 73202081; Compression spring VD-264B Country of origin: DE, German; Compression spring VD-264B Product image - Compression springs VD-264B QR-Code: Compression spring VD-264B
