Home » Products » Compression springs » vd-313v Url teilen URL was copied to clipboard, successfully ! Overview The Item has been added to your shopping cart. Compression spring VD-313V Stainless steel Ø 4 x 66 x 613 mm Scaled prices - Compression spring VD-313V Quantity Single price [EUR] 1 16.3800 EUR 2 13.0500 EUR 3 9.0700 EUR 7 7.2200 EUR 17 5.7200 EUR 37 4.9500 EUR 75 4.9100 EUR 125 4.9100 EUR 175 4.9100 EUR 250 4.9100 EUR 350 4.9100 EUR Compression spring Buy Product image Compression spring VD-313V Quantity:Quantity: Add to shopping cart Technical Data - Compression spring VD-313V Formula symbols Value Unit Description Material 1.4310 - Type of material Spring ends Closed and ground - Spring ends F1 N prestressed spring force L1 mm Prestressed spring length s1 mm Prestressed spring deflection F2 N Loaded spring force L2 mm Loaded spring length s2 mm Loaded spring deflection d 4 mm Wire diameter Di mm Inner coil diameter D 66 mm Mean coil diameter De 70 mm Outer coil diameter Dd 60 mm maximum diameter of mandrel Dh 73.7 mm minimum diameter of bush L0 613 mm unstressed spring length Lk 527.48 mm buckling length Fn 257.107 N maximum force in static use Ln 101.52 mm Minimum length in static use sn 511.48 mm Maximum spring deflection in static use Fndyn 249.184 N maximum force in dynamic use Lndyn 117.28 mm Minimum length in dynamic use shdyn 111.22 mm Maximum stroke in dynamic use S 39.29 mm pitch of spring n 15.5 pc. number of active coils nt pc. total number of coils R 0.503 N/mm Spring rate Weight 360.431 g weight of one spring Fntol 17.21 N (+/-) tolerance of maximum force in static use Fndtol 17.07 N (+/-) tolerance of maximum dynamic force Detol 1.4 mm (+/-) tolerances of outer coil diameter L0tol 21.73 mm (+/-) tolerance of unstressed spring length Price group #AR - price group F1tol N (+/-) tolerance of prestressed spring force F2tol N (+/-) tolerance of loaded spring force Technical drawing Compression spring Datasheet Compression spring VD-313V Stainless steel Ø 4 x 66 x 613 mm Datasheet download pdf file Metal spring characteristic Compression spring VD-313V Stainless steel Ø 4 x 66 x 613 mm Metal spring characteristic download pdf file CAD data Compression spring VD-313V Stainless steel Ø 4 x 66 x 613 mm CAD models download: step, stl, iges ... force-path-calculation Compression spring VD-313V Stainless steel Ø 4 x 66 x 613 mm force-path-calculation Compression spring VD-313V Inquiry formular Compression spring VD-313V Stainless steel Ø 4 x 66 x 613 mm Inquiry formular Compression spring VD-313V Similar compression springs to Compression spring VD-313V Stainless steel Ø 4 x 66 x 613 mm Below you will find similar Compression Springs that differ from the current spring in terms of material, dimensions and spring force. The spring highlighted in green is the most similar. A similar Compression Spring made from a different material The Compression Spring shown below has the same dimensions but is made of a different material. Please check the spring forces. article number Material d (mm) De (mm) L0 (mm) Fn (N) Ln (mm) sn (mm) n (pc.) R (N/mm) Similarity in %: Overall | Geometrie | Load | Stiffness VD-313V 1.4310 4 70 613 257.107 101.52 511.48 15.5 0.503 100.0 | 100.0 | 100.0 | 100.0 D-313V EN 10270-1 4 70 613 299.346 101.52 511.48 15.5 0.585 92.9 | 100.0 | 92.9 | 85.9 Number of similar metal springs: 2 Similar Compression Springs with varying levels of spring force To compare forces, enter the length of the loaded spring [L2] or the loaded spring deflection [s2] and click [Update]. Dimensions are subject to a tolerance of up to +/- 30 %. L2 (mm) Loaded spring length s2 (mm) Loaded spring deflection Priority De (mm) Outer coil diameter L0 (mm) unstressed spring length R (N/mm) Spring rate article number De (mm) L0 (mm) R (N/mm) Material Fn (N) Ln (mm) sn (mm) Similarity in %Overall | Geometrie | Load | Stiffness VD-289C 55 497 0.426 1.4310 177.398 80.46 416.54 79.9 | 79.9 | 75.2 | 84.7 VD-313V 70 613 0.503 1.4310 257.107 101.52 511.48 100.0 | 100.0 | 100.0 | 100.0 VD-313E 60 516 0.529 1.4310 225.606 89.12 426.88 89.1 | 86.6 | 85.6 | 95.1 VD-313U-01 70 492 0.577 1.4310 232.327 89.45 402.55 88.4 | 93.4 | 84.5 | 87.1 VD-339J 75 615 0.661 1.4310 332.691 111.4 503.6 86.0 | 94.0 | 87.9 | 76.1 VD-339Z 85 691 0.689 1.4310 390.027 125.01 565.99 78.3 | 83.7 | 78.1 | 72.9 VD-318A 54 490 0.796 1.4310 288.238 128.09 361.91 76.3 | 85.7 | 80.0 | 63.1 VD-313U 70 379 0.82 1.4310 257.266 65.32 313.68 76.4 | 87.3 | 80.6 | 61.3 VD-318 54 490 0.969 1.4310 371.241 106.74 383.26 69.9 | 85.7 | 72.1 | 51.9 VD-344A 68 585 0.972 1.4310 412.591 160.54 424.46 71.7 | 90.9 | 72.7 | 51.7 VD-339H 75 380 1.078 1.4310 332.239 71.76 308.24 65.6 | 81.4 | 68.8 | 46.6 VD-339Z-04 75 430 1.181 1.4310 384.903 104.1 325.91 63.0 | 81.2 | 65.3 | 42.6 VD-344 68 585 1.182 1.4310 533.439 133.78 451.22 67.2 | 90.9 | 68.2 | 42.5 VD-343A 68 395 1.182 1.4310 308.819 133.78 261.22 63.4 | 80.5 | 67.2 | 42.5 VD-369A 86.3 720 1.197 1.4310 618.824 202.81 517.19 62.9 | 76.6 | 70.2 | 42.0 VD-364J-05 56 605 1.397 1.4310 410.499 311.18 293.82 59.9 | 83.8 | 60.0 | 36.0 VD-369 86.3 720 1.455 1.4310 801.833 169 551 57.9 | 76.6 | 62.4 | 34.5 Number of similar metal springs: 16 Customs tariff number: 73202081; Compression spring VD-313V Country of origin: DE, German; Compression spring VD-313V Product image - Compression springs VD-313V QR-Code: Compression spring VD-313V
